Pioneer TS-W3020PRO 12" 3500W Max Dual 2-Ohm Voice Coil DVC Car Audio Subwoofer

Pioneer TS-W3020PRO 12" 3500W Max Dual 2-Ohm Voice Coil DVC Car Audio Subwoofer

$299.99 USD
$299.99 USD
Sale Sold out
Shipping calculated at checkout.
BRAND NEW

PIONEER TS-W3020PRO

PRO Series | 12-Inch 3500 Watts Max Dual 2-Ohm DVC Subwoofer

Key Features:

  • Power handling: 1800W RMS / 3500W Max.
  • Optimally Blended Pulp Cone Woofer
  • Urethane Surround
  • 4-layer Copper Long Voice Coil with Aluminum Bobbin
  • Frequency response: 20Hz to 200Hz
  • Impedance: Dual 2 ohms
  • Sensitivity: 88dB (1W/1M)
Specifications:

  • Diameter: 12”
  • Mounting Depth (mm/inch): 154mm - 6.06"
  • Cut-out dimension (mm/inch): 282mm - 11.1"
  • Sound Pressure Level (Sensitivity): 88dB (± 1.5dB)
  • Frequency Range: 20 Hz to 200 Hz
  • Continuous Power Handling (RMS): 1800 Watts
  • Maximum Peak Power Handling: 3500 Watts
  • Nominal Impedance: Dual 2 ohm
  • Resonance Frequency (f0): 47.9
  • Cone Material: Blended Pulp / Cellulose
  • Surround Type: Rolled
  • Surround Material: Urethane
  • Spider Material: Polycotton
  • Magnet Material: Ferrite
  • Voice Coil Wire Material: 4-layer Copper Long Voice Coil with Aluminum Bobbin
  • Qts: 1.3
  • Vas (liters/cu ft.): 8.3 - 0.293
  • Xmax (mm/inch): 22.8 - 0.897
  • Recommended Volume: Sealed - 1.25 cu.ft (34.4 liters) / Ported 1.75 cu.ft (50 liters)
