Orion
Orion CBA3500.4 4-Channel 3500 Watts Max Power Class-A/B Car Audio Amplifier
Orion CBA3500.4 4-Channel 3500 Watts Max Power Class-A/B Car Audio Amplifier
Regular price
$129.95 USD
Regular price
Sale price
$129.95 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
BRAND NEW
ORION CBA3500.4
COBALT SERIES | 4-Channel 3500 Watts Max Power Class-A/B Car Audio Amplifier
The ORION CBA3500.4 COBALT Series 3500 Watts MAX 4-Channel Class A/B Amplifier exemplifies the pinnacle of audio excellence. Through advanced features and meticulous engineering, this amplifier transcends conventional boundaries, delivering an extraordinary fusion of power, accuracy, and control to your car audio system.
Key Features:
- Class A/B Amplification
- 3500 Watts Max Power
- All MOSFET Power Supply & Output Stage
- Heavy Gauge / High Current Custom Power and Speaker Terminals
- RCA Out Throughput
- 12dB Octave Low-Pass Filter
- Electronic Crossover Network
- Bass Boost Circuit
- Intelligent Power and Protection LED Indicator
- Soft Turn-on/Turn-off Turn-On Delay
- Fault and Protection Monitoring
- 4-Way Protection: Thermal, DC offset, Short Protection, under & over voltage
Specifications:
- Positive Terminals: 1 x 4 AWG.
- Negative Terminals: 1 x 4 AWG.
- Remote Turn-ON Signal: 10 AWG.
- Speaker Output Terminals: 10 AWG.
- Frequency Response: 10Hz - 30kHz
- High Pass Crossover Continuously variable (50-1.2kHz)
- Low Pass Crossover Continuously variable (40-250Hz)
- Supply Voltage: 10 - 16V
- Input Impedance: 22kOhm - Signal to Noise Ratio: >90dB
- Bass Boost: 0/3/6dB Switch
- Variable Input Level Control: 0.2V - 6.0V
- Fuses: 90A recommended (3 x 30A ATC)
- Dimensions (L x W x H): 14.12" x 7.09" x 2.13" (359x180x54mm)
