BRAND NEW

JL AUDIO 10TW3-D8

10-inch 400 Watts  RMS Dual 8-Ohm Voice Coil Shallow-Mount Subwoofer

TW3s are optimized for small enclosures and offer our tab-ear mounting design to maximize cone area within their mounting footprints. We know you’re going to love working with these amazing Subwoofers.

Key Features:

  • Very shallow mounting depth (3.25 / 3.50 Inches)
  • No pole vent: permits mounting close to the rear wall of enclosure.
  • Very small sealed enclosure volume requirements
  • Very long linear excursion capability (0.60 In / 15.2 mm, one-way)
  • DMA-optimized motor designs
  • “concentric tube” architecture
  • Patented “floating cone attach method” technology
  • Cast alloy frame
  • Injection-molded, mica-filled polypropylene cone
  • Rubber surround
  • Aluminum-alloy dust cap and rear cap with JL Audio logo
  • Precision-built in USA at JL Audio’s Miramar, Florida factory with global components
Specifications:

  • Continuous Power Handling (RMS): 400 W
  • Recommended Amplifier Power (RMS): 200 - 400 W
  • Nominal Impedance (Znom): Dual 8 Ω
  • Nominal Diameter: 10 in / 250 mm
  • Overall Diameter: A1: 11.2 in / 284 mm | 10.5 in / 267 mm
  • Mounting Hole Diameter: 9.625 in / 244 mm
  • Bolt Hole Circle Diameter: 10.5 in / 267 mm
  • Motor Outer Diameter: 5.1 in / 130 mm
  • Mounting Depth: 3.25 in / 83 mm
  • Driver Displacement: 0.019 cu ft / 0.54 L
  • Net Weight: 10.1 lb / 4.6 kg
Parameters:

  • Free Air Resonance (Fs): 39.262 Hz
  • Electrical “Q” (Qes): 0.825
  • Mechanical “Q” (Qms): 9.84
  • Total Speaker “Q” (Qts): 0.761
  • Equivalent Compliance (Vas): 0.510 cu ft / 14.44 L
  • One-Way Linear Excursion (Xmax)*: 0.6 in / 15.2 mm
  • Reference Efficiency (no): 0.23%
  • Efficiency (1 W / 1 m)**: 82.27 dB SPL
  • Effective Piston Area (Sd): 56.532 sq in / 0.0365 sq m
  • DC Resistance (Re)***: 15.008 Ω
