Infinity BASSLINK SM2 8" Shallow-Profile Powered Underseat Subwoofer w/ 125W Amp
Infinity BASSLINK SM2 8" Shallow-Profile Powered Underseat Subwoofer w/ 125W Amp
Regular price
$349.95 USD
Regular price
Sale price
$349.95 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
BRAND NEW
INFINITY BASSLINK SM2
8-inch Shallow-Profile Powered Underseat Subwoofer with 125W Amplifier
Key Features:
Proprietary, shallow-profile woofer
The 8" (200mm) subwoofer in the BassLink SM2 is designed specifically to provide low distortion and great bass performance in its custom-tuned ABS enclosure with a remarkably compact footprint.
Efficient Class D amplifier
The amp that powers the BassLink SM2 produces minimal heat, and it doesn’t require a lot of current from the car’s electrical system.
Intelligent electronic design
The BassLink SM2 employs high-pass filters and limiters that deliver exceptional at-the-limits performance.
Crossover control
A variable crossover control (50Hz – 120Hz) lets you adjust how much upper bass and mid-bass the BassLink SM2 produces. Fine-tune the crossover to achieve a smooth transition from the BassLink SM2 to the rest of the system’s speakers.
Flexible EQ adjustments
Level control adjusts the BassLink SM2’s volume to the other speakers in your system, while Bass Boost control lets you minimize peaks or dips in bass frequencies in your car’s acoustic environment.
Line- and high-level inputs
For added installation flexibility, the BassLink SM2 features both line- and high-level inputs. If you use the high-level inputs to connect the BassLink SM2 to the head unit, an input load switch lets you switch from “Low” to “High” to achieve optimum results.
Wired, remote level control capability
The BassLink SM2 is compatible with the JBL GTO-RBC included, which enables you to control the bass level remotely.
General Specifications:
- Woofer: 8" (200mm)
- Amplifier Power: 125W RMS
- Frequency Response: 35Hz – 120Hz
- Fuse: 15A
- Maximum Current Draw: 12A
- Quiescent Current Draw: <800mA
- Input Sensitivity: 0.05V – 2V Line-Level Input; 0.5V – 20V High-Level Input
- Crossover Frequency: 50Hz – 120Hz
- Crossover Slope: 12dB/octave
- Bass Boost: 0dB to +9dB @ 70Hz
- Dimensions: (L x W x H)13-9/16" x 9-7/8" x 2-13/16" (344mm x 250mm x 71mm)
In The Box:
- 1x powered woofer enclosure
- 4x mounting screws
- 1x Owner’s manual
- 1x Remote Bass Level Control
