DS18 PRO-CF8.4NR 8" 600W Max 4-Ohm Carbon Fiber Cone Mid-Bass Loudspeaker

DS18 PRO-CF8.4NR 8" 600W Max 4-Ohm Carbon Fiber Cone Mid-Bass Loudspeaker

$209.95 USD
$209.95 USD
Sale Sold out
Shipping calculated at checkout.
BRAND NEW

DS18 PRO-CF8.4NR

8-inch 600 Watts Max 4-Ohm Carbon Fiber Cone Mid-Bass Loudspeaker

With its water-resistant construction, Neodymium magnet, high-tech carbon fiber cone, and super-strong rubber surround, the PRO-CF8.4NR offers exceptional performance, unmatched versatility, and a visually stunning presence.

Key Features:

  • 8" Mid-Bass
  • Water Resistant Carbon Fiber Cone
  • RMS Power: 300 Watts(600 Watts Peak)
  • Impedance: 4 Ohm
  • Neodymium Magnet
  • 99dB
Specifications:

  • SKU: PRO-CF8.4NR
  • Nominal Diameter: 8" / 203mm
  • Nominal Impedance: 4 OHMS
  • RMS Power Handing: 300 WATTS
  • Maximum Power Handing: 600 WATTS
  • Sensitivity (1w/1m): 99 dB
  • Frequency Response: 63Hz - 12KHz
  • Recommended Hi Pass Crossover: 80 Hz
  • Voice Coil Diameter: 2" / 50 mm
  • Voice Coil Former Material: Kapton
  • Winding Material: CCAW
  • Basket Material: Steel
  • Magnet Weight: 10.5Oz / 0.3Kg
Thiele & Small Parameters:

  • Vas: 72.15L / 2.584 ft3
  • Xmax: 2.5 mm
  • Fs: 61 Hz
  • Qms: 10.169
  • Qes: 0.344
  • Qts: 0.333
  • Re: 3.46 OHM
Measurements:

  • Overall Diameter: 8.29" / 210.7 mM
  • Front Mount Baffle Cutout: 7.16" / 182 mm
  • Mounting Depth: 3.2" / 81.5 mm
  • Overall Depth: 3.38" / 86 mm
  • Product Weight: 4.5 lbs
  • Product Dimensions: 9.75 x 9.75 x 4.75
  • Sold In: Piece
