DS18 DSP2.8DBT 2-Channel In & 8-Channel Out Digital Sound Processor w/ Bluetooth
DS18 DSP2.8DBT 2-Channel In & 8-Channel Out Digital Sound Processor w/ Bluetooth
Regular price
$199.95 USD
Regular price
Sale price
$199.95 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
BRAND NEW
DS18 DSP2.8DBT
2-Channel In and 8-Channel Out Digital Sound Processor with Bluetooth & LCD Screen
Overview:
The DS18 DSP2.8DBT is an advanced digital signal processor designed for use in car audio systems. It features 8 channels of processing and has the ability to adjust the crossover points, equalization, and other sound parameters to optimize the audio performance. The device has Bluetooth connectivity for easy setup and control using a compatible smartphone app. It also has a compact design for easy installation in tight spaces. With a maximum signal gain of 2.8 decibels, the DSP2.8DBT is capable of boosting the output of your audio system for a more powerful and dynamic sound.
Key Features:
- Easy-to-use software found on Google Play or the App Store to fine-tune and monitor every aspect of your signal processing.
- Crossover with filters; Butter worth, Linkwitz-Riley and Bessel, with attenuations from 6dB/OCT until 48dB/OCT.- Bluetooth connectivity to allow for easy and accessible audio tuning
- Automatic or manual limiter function with threshold, attack and release.
- Input equalizer with 15 bands between 1/3 Octave.
- Parametric equalizer with 3 independent bands per channel.
- Adjustable time delay per channel.
- 2 RCA Channel Audio Input.
- 8 RCA Channel Outputs.
- 3 Audio Custom Presets.
- Pink Noise Generator.
Specifications:
- Input Type: Unbalanced
- Input Connection: RCA
- Input Max Level: Up to 6 Volts RMS
- Input Impedance: 47k Ohms
- Output Type: Unbalanced
- Output Connection: RCA
- Output Max Level: 2 Volts RMS
- Output Impedance: 47k Ohms
- Resolution: 24 Bits
- Sample Frequency: 48KHz
- Latency Frequency: 1.08 Ohms
- Range Frequency: 15Hz a 22KHz (-1dB)
- THD+N Max: 0.01%
- Signal to Noise Ratio: 100dB
- Pow Supply Voltage: 10 ~ 15 VDC
- Consumption: 300mA (5W)
- Fuse: 2 A
Dimensions:
- Length: 9.84“
- Width: 4.72“
- Height: 1.18“
- Weight: 13.4 Oz
