DS18 6XL650N-4 6.5" 650W Max 4-Ohms Neodymium Rings Mid-Range Loudspeaker

Name: DS18 6XL650N-4 6.5" 650W Max 4-Ohms Neodymium Rings Mid-Range Loudspeaker
Brand: DS18
SKU: 6XL650N4
Price: 169.95 USD
Availability: OutOfStock

$169.95 USD

Sale Sold out

Shipping calculated at checkout.

Product variants

Quantity

BRAND NEW

DS18 6XL650N-4

6.5-Inch 650 Watts Max 4-Ohms Neodymium Rings Mid-Range Loudspeaker

Key Features:

6.5" Mid-Range
MAX Power: 650 Watts
RMS Power: 325 Watts
Impedance: 4-Ohm
Neodymium Magnet
98.5dB

Specifications:

Nominal Diameter: 6.5" / 165mm
Nominal Impedance: 4 Ohm / 8 Ohm
RMS Power Handling: 325 watts
MAX Power Handling: 650 watts
Sensitivity (1w/1m): 98.5dB
Frequency Response: 60Hz-12.5KHz
Recommended HI Pass Crossover: 100Hz
Sold in Pair or Single: Single
Grill Included: No

Motor Specs:

Voice Coil Diameter: 2" / 50.8 mm
Voice Coil Former Material: Kapton
Winding Material: CCAW
Cone Material: Non-pressed Paper
Dust Cap Material: Paper
Surround Material: Cloth
Basket Material: Aluminum
Basket Color | Finish: Satin Black
Magnet Material: Neodymium
Magnet Weight: 11.4 Oz
Displacement Volume: 0.34L / 0.012ft3

Thiele & Small Parameters:

Vas: 5.86L / 0.206ft3
Xmax: 3.7 mm
Fs: 100Hz
Qms: 4.385
Qes: 0.256
Qts: 0.242
Mms: 11.278
Cms: 0.214 mm/N
BL: 9.449
Le: 0.1744 mH
Sd: 136.85 cm²
Re: 3.2 ohm
Mmd: 11.278 g

Measurement:

Overall Diameter: 6.7" / 170mm
Overall Depth: 3.19" / 81mm
Front Mount Baffle Cutout: 5.9" / 150mm
Mounting Depth: 2.83" / 72mm
Motor Diameter: 4.13" / 105 mm
