Diablo DB-800.4D 4-Channel 1600W Max Full-Range Super Mini Class-D Car Amplifier

Name: Diablo DB-800.4D 4-Channel 1600W Max Full-Range Super Mini Class-D Car Amplifier
Brand: Diablo
SKU: DB-800.4D
Price: 179.99 USD
Availability: InStock

$179.99 USD

Sale Sold out

Shipping calculated at checkout.

Product variants

Quantity

BRAND NEW

DIABLO DB-800.4D

4-Channel 1600W Max Full-Range Super Mini Class-D Car Audio Amplifier

Specifications:

4Ch Full-Range Super Mini Class D Amplifier
Maximum Output Power @ 14.4V (2 Ohm) 4 x 400W MAX
RMS Power @ 14.4V (2 Ohm) 4 x 195W RMS
Maximum Output Power @ 14.4V (4 Ohm) 4 x 226W MAX
RMS Power @ 14.4V (4 Ohm) 4 x 113W RMS
Maximum Output Power@14.4V (4 Ohm bridged) 2 x 800W MAX
RMS Power (4 Ohm bridged) 2 x 385W RMS
Input Sensitivity: 200MV
Signal-to-Noise Ratio: 101dB
Frequency Response: 15Hz-20KHz

Crossover:

H.P.F. (High Pass Filter) 40 to 3KHz Variable
L.P.F. (Low Pass Filter) 40 to 3KHz Variable
Bass Boost: 0-12dB (50Hz)
Protection System: Output Short/High/Low Supply
Voltage/Thermal Protection
Minimum Supply Voltage: 9V
Maximum Supply Voltage: 16V
