BRAND NEW
AUDIOCONTROL SPC-12S4
SPACE Series | 12" 600W Max Single 4-Ohm Voice Coil SVC Car Audio Subwoofer
Key Features:
- Low-Profile Shallow Mount Subwoofer
- Fiber Matrix Injection Molded Polypropylene Cone
- Weather-Resistant Design
- 3-Layer High Temp Voice Coil Former
- Optimal Thermal Efficiency
- Wrap-Sealed Rubber Gasket to Protect Enclosure Interior
- Removable Subwoofer Grille Included
Thiele/Small Parameters:
- Nominal Impedance (Z): 4 ohms
- DC Resistance (Re) ]]: 3.2 ohms
- Resonance Frequency (Fs): 30.7061 Hz
- Piston Area (Sd): 0.0511 m2
- Force Factor (BL): 12.4924 T.m
- Mechanical Q Factor (Qms): 3.7494
- Electrical Q Factor (Qes): 0.5764
- Total Q Factor (Qts): 0.4996
- Sensitivity 1W/M (SPL): 87.3024
- Mechanical Comp (Cms): 0.1844 mm/N
- Moving Mass (Mms): 145.7101 g
- Linear Excursion (Xmax): 9 mm
- Volume Acoustic Comp (Vas): 67.1494 Ltr/2.371348 cu ft
- Reference Efficiency (NO.): 0.32% RMS
- Power (Pe): 400 Watts
- Frequency Response: 20-250 Hz
- Voice Coil Diameter: 2.5 in/63.5 mm
- Displacement: 0.0619 cu ft/1.752 Ltr
Dimensions:
- Overall Dimensions: 12.37 in/316 mm
- Cut Out Diameter: 11.10 in/282 mm
- Mounting Depth: 3.94 in/100 mm
- Mounting Height (w/o Grille): 0.71 in / 18mm
- Mounting Height (w/ Grille): 1.42 in/36mm
Ported Enclosure:
- External Dimensions: 24.00″ W × 15.00″H × 15.00″D
- Net Internal Volume: 2.02 ft3
- Total Internal Volume: 2.28 ft3
- Gross External Volume: 3.01 ft3
- Material Thickness: 0.75″
- Tuning Frequency: 40 Hz
- Port Area” 27.00 inch2
- Port Inlet: 2.00″W× 13.50″H
- Port Length: 16.25″
- F3 (Hz): 40
Sealed Enclosure:
- External Dimensions: 32″ W × 15.00″H × 7.00″D
- Net Internal Volume: 1.25 ft3
- Total Internal Volume: 1.31 ft3
- Gross External Volume: 1.94 ft3
- Material Thickness: 0.75″
- F3 (Hz): 51
- Qtc: 0.765
*Enclosure size recommendations do not include driver and/or port displacement
